VersaUV LEJ-640 Specifications
| Model | LEJ-640 | ||
| Printing technology | Piezoelectric inkjet | ||
| Media | Width | Roll media : 210 to 1625 mm (8.3 to 64 in.) Rigid media, cut media : 250 to 1625 mm (9.9 to 64 in.) |
|
| Thickness | Roll media : Max. 1.0 mm (39 mil) with liner Rigid media, cut media : Max. 13 mm (0.51 in.) |
||
| Weight | Roll media : Max. 40 kg (88 lb) Rigid media, cut media : Max. 12 kg (26 lb) |
||
| Roll outer diameter | Max. 210 mm (8.3 in.) |
||
| Core diameter*1 | 76.2 mm (3 in.) or 50.8 mm (2 in.) | ||
| Printing width*2 | Max. 1615 mm (63.6 in.) | ||
| Ink | Type | ECO-UV INK / ECO-UV S INK | |
| Capacity | 220 cc / 500 cc | ||
| Colours | ECO-UV INK: 6 colours (Cyan, Magenta, Yellow, Black, White, Gloss) ECO-UV S INK: 5 colours (Cyan, Magenta, Yellow, Black, White) |
||
| Print resolution (dots per inch) |
Max. 1440 dpi | ||
| Distance accuracy*3 | Error of less than ±0.3% of distance travelled, or ±0.3 mm, whichever is greater | ||
| Media take-up system | Roll outer diameter allowing take-up | Max. 210mm (8.3in.) | |
| Weight allowing take-up | Max. 40kg (88lb) | ||
| Connectivity | Ethernet (10 BASE-T/100 BASE-TX, automatic switching) | ||
| Power-saving function | Automatic sleep feature | ||
| Power requirements | AC 100 to 240 V ± 10%, 5.7A, 50/60 Hz | ||
| Power consumption | During operation | 500 W | |
| Standby mode | 15.2 W | ||
| Acoustic noise level |
During operation |
64 dB (A) or less |
|
| Sleep mode |
40 dB (A) or less | ||
| Environment | Power on*4 | Temperature: 20 to 32°C (68 to 90°F) [22°C (72°F) or higher recommended] , humidity: 35 to 80% RH (no condensation) |
|
| Power off | Temperature: 5 to 40°C (41 to 104°F), humidity: 20 to 80% RH (no condensation) | ||
| Dimensions (with stand) | With table unit *5 |
3184 (W) × 3658 (D) × 1281 (H) mm (126 × 145 × 51 in.] | |
| Without table unit *5 | 3184 (W) × 836 (D) × 1281 (H) mm (126 × 33 × 51 in.) | ||
| Weight (with stand) | With table unit *5 |
316 kg (697 lb) |
|
| Without table unit *5 | 240 kg (530 lb) | ||
| Included items | Roland VersaWorks Dual RIP Software, stand, table unit (RU-640 and MB-640), power cable, media clamps, replacement blade for separating knife, User's Manual, etc. | ||
*1 The media holder of this machine is exclusive use for the media of paper tube (core) inner diameter 76.2 mm (3 in.). To use 50.8 mm (2 in.) media, the optional media flanges are required.
*2 The length of printing is subject to the limitations of the program.
*3 Media type: Media specified by Roland DG Corp. Temperature: 25°C (77°F), humidity: 50%RH. Roll media must be loaded correctly. Excluding expansion/contraction of the media. All correction or adjustment function of this machine has been made properly. The grit rollers are positioned correctly on top of the media. With Roland PET film, print travel: 1 m. When not using table unit.
*4 Operating environment.
*5 The "table unit" indicates RU-640 and MB-640.
Specifications, designs and dimensions listed may be subject to change without notice.
| Operating System | Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate/Professional (32/64 bit) |
|---|---|
| CPU | Intel Core™ 2 Duo, 2.0 GHz or faster recommended |
| RAM | 2GB or more recommended |
| Video card and monitor | A resolution of 1280 x 1024 or more recommended |
| Free hard disk space | 40 GB or more recommended |
| Optical drive | DVD-ROM |
| Other | Internet connection recommended |
