VersaCAMM SPi Series

VersaCAMM SP-300i & SP-540i Large-Format Color Printers/Cutters Specifcations

SP-540i SP-300i
Printing technology Piezoelectric inkjet
Media Width 210 to 1371 mm 182 to 762 mm
Thickness Maximum 1 mm with liner, for printing Maximum 0.4 mm with liner and 0.22 mm without liner, for cutting
Roll Outer Diameter Maximum 180 mm
Roll Weight Maximum 30 kg Maximum 20 kg
Core Diameter 50.8mm or 76.2 mm
Printing/Cutting width (*1) Maximum 1346 mm Maximum 736 mm
Print Speed
Profile Mode Resolution
Banner High Speed 360x720 7.8 sqm/hr 6.5 sqm/hr
Standard 720x720 4.8 sqm/hr 4.1 sqm/hr
High Quality 1440x720 1.8 sqm/hr 1.6 sqm/hr
Vinyl High Speed 360x720 6.7 sqm/hr 5.7 sqm/hr
Standard 720x720 4.8 sqm/hr 4.1 sqm/hr
High Quality 1440x720 1.8 sqm/hr 1.6 sqm/hr
Ink Cartridges Types 220cc cartridge/ 440cc cartridge, ECO-SOL MAX
  Colors Four colors (cyan, magenta, yellow, black)
Printing Resolution (dpi) Maximum 1440 dpi
Cutting Speed 10 to 300 mm/s
Blade Force 30 - 300 grams force
Cutting Blade Type Roland CAMM-1 series compatible
Blade Offset 0 to 1.5mm
Software resolution (when cutting) 0.025 mm/step
Distance accuracy (when printing) (*2) (*3) Error of less than +0.3% of distance traveled, or +0.3mm, whichever is greater
Distance accuracy (when cutting) (*3) Error of less than +0.4% of distance traveled, or +0.3mm, whichever is greater When distance correction has been performed (when the setting for [CUTTING MENU] - [CALIBRATION] has been made): Error of less than +0.2% of distance traveled, or +0.1mm, whichever is greater
Repeatability (when cutting) (*3)(*4) +0.1 mm or less
Alignment accuracy
for printing and cutting (*3)(*5)
+0.5 mm or less
Alignment accuracy
for printing and cutting when reloading media (*3)(*6)
Error of less than +0.5% of distance traveled, or +3mm, whichever is greater
Media heating system (*7) Print heater, setting range for the preset temperature: 30 to 45℃) Dryer, setting range for the preset temperature: 30 to 50℃)
Connectivity Ethernet (10BASE-T/100BASE-TX, automatic switching)
Power-saving function Automatic sleep feature
Power requirements AC 100 to 120V +10%, 7.6A, 50/60 Hz AC 220 to 240V +10%, 3.9A, 50/60 Hz AC 100 to 120V +10%, 5.5A, 50/60 Hz AC 220 to 240V +10%, 2.8A, 50/60 Hz
Power During Operation Approx 1030 W Approx 730 W
Sleep Mode Approx 14 W
Acoustic noise level During operation 64 dB (A) or less
During standby 40 dB (A) or less
Dimensions (with stand) (*8) 2310 x 740 x 1125 mm 1700 x 740 x 1125 mm
Weight (with stand) 112 kg 89 kg
Environmental Power on (*9) Temperature:15 to 32℃ (20℃ or more recommended), humidity: 35 to 80%RH (non-condensing)
Power off Temperature: 5 to 40℃), humidity: 20 to 80%RH (non-condensing)
Accessories Stand, power cord, blade, blade holder, media clamps, media flanges, replacement blade for separating knife, cleaning kit, RVW RIP, User Manual, etc
