TrueVIS VG Series Specifications
|Printing technology||Piezoelectric inkjet|
|Media||Width||210 to 1625 mm (8.3 to 64 in.)||210 to 1371 mm (8.3 to 54 in.)|
|Thickness||Max. 1.0 mm with liner for printing. Max. 0.4 mm with liner and 0.22 mm without liner for cutting|
|Roll outer diameter||Max. 210 mm (8.3 in.)|
|Roll weight||Max. 40 kg (88 lb.)
||Max. 30 kg (66 lb.)
|Core diameter *1||76.2 mm (3 in.) or 50.8 mm (2 in.)|
|Printing/cutting width *2
||Max. 1600 mm (63 in.)
||Max. 1346 mm (53 in.)
||Types||TrueVIS INK 500 cc pouch
4 colours (Cyan, Magenta, Yellow, Black)
7 colours (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black)
8 colours (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, White)
|Print resolution (dots per inch)||Max. 900 dpi|
|Cutting speed||10 to 300 mm/s (0.4 to 11.8 in/s)|
|Blade force *3||30 to 500 gf|
|Blade||Type||Roland CAMM-1 series blade|
||0.000 to 1.500 mm (0.0 to 59.1 mil)|
|Software resolution (when cutting)||0.025 mm/step (0.98 mil/step)|
|Distance accuracy (when printing) *4 *5||Error of less than ±0.3 % of distance travelled or ±0.3 mm (±11.8 mil), whichever is greater|
|Distance accuracy (when cutting) *4||
Error of less than ±0.4 % of distance travelled or ±0.3 mm (±11.8 mil), whichever is greater. When distance correction has been performed (when the setting for [CUTTING MENU] - [CALIBRATION] has been made): Error of less than ±0.2 % of distance travelled or ±0.1 mm (±3.9 mil), whichever is greater
|Repeatability (when cutting) *4 *6||±0.1 mm (±3.9 mil) or less|
|Alignment accuracy for printing and cutting *4 *7||±0.5 mm (±19.7 mil) or less|
|Alignment accuracy for printing and cutting when reloading media *4 *8||Error of less than ±0.5 % of distance travelled by media or ±3 mm (±0.2 in.), whichever is greater|
|Media heating system *9||
Print heater set temperature 30 to 45°C (86 to 112°F)
Dryer set temperature 30 to 50°C (86 to 122°F)
|Connectivity||Ethernet (100BASE-TX/1000BASE-T, automatic switching). Bluetooth enabled Roland DG Mobile Panel.|
|Power-saving function||Automatic sleep feature|
|Power requirements||AC 100 to 120 V ±10%, 9.8A, 50/60 Hz or AC 220 to 240 V ±10%, 5.2 A, 50/60 Hz||AC 100 to 120 V ±10%, 7.9 A, 50/60 Hz or AC 220 to 240 V ±10%, 4.1 A, 50/60 Hz|
|Power consumption||During operation||Approx. 1270 W||Approx. 1030 W|
|Sleep mode||Approx. 40 W||Approx. 15.1 W|
|Acoustic noise level||During operation||64 dB (A) or less|
|During standby||41 dB (A) or less|
|Environment||Power on *10||Temperature: 20 to 32°C (68 to 90°F), humidity: 35 to 80 % RH (no condensation)|
|Power off||Temperature: 5 to 40°C (41 to 104°F), humidity: 20 to 80 % RH (no condensation)|
|Dimensions (with stand)||2945 (W) x 745 (D) x 1310 (H) mm (116 x 29.4 x 51.6 in.)||2685 (W) x 745 (D) x 1310 (H) mm (105.8 x 29.4 x 51.6 in.)|
|Weight (with stand)||205 kg (451.9 lb.)||191 kg (421 lb.)|
|Included items||Exclusive stands, power cord, media clamps, media holders, replacement blade for separating knife, softaware RIP, User's Manual, etc.|
|4 Colour CMYK||VG-640||VG-540|
||900 x 600||8||10.6 sqm/hr||9.9 sqm/hr|
|Standard||900 x 600||6||14.2 sqm/hr||13.3 sqm/hr|
|High Speed||600 x 600||3||23.3 sqm/hr||22.2 sqm/hr|
|Billboard||600 x 600||2||34.7 sqm/hr||32 sqm/hr|
|7 Colour (CMYKLcLmLk)|
|High Quality||900 x 600||13||6.2 sqm/hr||5.9 sqm/hr|
|Standard||900 x 600||9||9.4 sqm/hr||8.9 sqm/hr|
|High Speed||600 x 600||5||13.7 sqm/hr||13.2 sqm/hr|
*1 The media holders of this machine are designed to be used exclusively with media that has a paper tube (core) with an inner diameter of 76.2 mm (3 in.). To use 50.8 mm (2 in.) media, the optional media flanges are required.
*2 The length of printing or cutting is subject to the limitations of the program.
*3 500 gf is the maximum instantaneous blade force. The blade force must be adjusted according to details such as the media thickness.
*4 Media type: Media specified by Roland DG Corporation. Temperature: 25°C (77°F), humidity: 50%. Roll media must be loaded correctly. Applicable when all pinch rollers that can be used with the media width are used. Side margins: 25 mm (1.0 in.) or more for both the left and right margins. Excluding expansion/contraction of the media. Not guaranteed when the print heater or dryer is used. Assumes all correction and adjustment functions of the machine have been used properly.
*5 Print travel: 1 m (39.4 in.).
*6 [PREFEED] menu item must be set to "ENABLE." Range for assured repetition accuracy: For media with a width exceeding 610 mm (24.0 in.): Length 4000 mm (157.5 in.). For media with a width of 610 mm (24.0 in.) or less: Length 8000 mm (315.0 in.).
*7 Provided that the media feed length is 3000 mm (118.1 in.) or less. Excludes the effects of slanted movement and of expansion and contraction of the media.
*8 Data size: VG-640: 1000 mm (39.4 in.) in the media-feed direction, 1600 mm (63.0 in.) in the carriage-movement direction. VG-540: 1000 mm (39.4 in.) in the media-feed direction, 1346 mm (53.0 in.) in the carriage-movement direction. No lamination. Automatic detection of crop marks at 4 points when media is reloaded. During cutting, [PREFEED] menu item must be set to "ENABLE." Excluding possible shift caused by expansion/contraction of the media and/or by reloading the media.
*9 Warm-up is required after the power is turned on. This may require 5 to 20 minutes, depending on the operating environment. Depending on the ambient temperature and the media width, the set temperature may not be reached.
*10 Operating environment.
Specifications, designs and dimensions listed may be subject to change without notice.
|Operating System||Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate/Professional (32/64 bit)|
|CPU||Intel Core™ 2 Duo, 2.0 GHz or faster recommended|
|RAM||2GB or more recommended|
|Video card and monitor||A resolution of 1280 x 1024 or more recommended|
|Free hard disk space||40 GB or more recommended|
|Other||Internet connection recommended|
